Product Group:Outsourced Product
Product Code: TX-SA-SCLM
Availability: Pre-Order

Qty

  • Email

    info@trilex.com.tr

  • Phone

    +90 543 692 62 76

  • Phone

    Mon. - Sat.: 08:30 - 18:00

Contact form

Container lashing midlocks to be placed between containers in a stack. used together with semi-automatic twist locks on deck between 20-foot containers in 40-foot bays, at mid-bay position resists horizontal and separation forces. fitted to underside of container on shore and automatically locks into lower container when placed on board. It is a type of temperature range used to secure and secure containers on container ships this mechanism is used to combine or separate containers on the ship deck and limit their movement

Material



Safe Working

Load

Breaking

Load

Weight

Forged cone and ductile

Fension

Shear



250 kN

210 kN



500 kN

420 kN



~ 4,15 kg
